Hepyc HSSCo Taper Shank Drill Bit 14.0mm DIN345N CM1

Industrial-grade cobalt HSSCo taper shank drill bit manufactured to DIN345N standards for precision drilling in high-tensile steels and demanding machining applications. Engineered for professional metalworking environments, this drill offers superior heat resistance, durability, and extended cutting life.

The 135° split point design improves centering accuracy and reduces drill wandering, while the 30° helix geometry ensures smooth chip evacuation and efficient cutting performance. The Morse taper CM1 shank provides secure machine fitment and reliable torque transmission for heavy-duty drilling operations.

Key Features & Benefits

• Cobalt High Speed Steel (HSSCo) construction
• DIN345N taper shank drill bit design
• 135° split point for accurate starting and reduced walking
• 30° helix for efficient chip evacuation
• Morse taper CM1 shank for secure holding
• Suitable for alloy steels and materials up to 1,100 N/mm² tensile strength

Technical Specifications

• Reference: 11220001400
• Drill Diameter: 14.0mm
• Overall Length (L): 189mm
• Flute Length (l): 108mm
• Shank Type: Morse Taper CM1
• Standard: DIN345N
• Material: Cobalt High Speed Steel (HSSCo)
• Point Angle: 135° Split Point
• Helix Angle: 30°

Hepyc cutting tools are designed for reliable industrial performance, delivering precision drilling, long tool life, and consistent results across fabrication, engineering, and metalworking applications.
